ASRock DeskMini 310 - Socket 1151 - Barebone - Mini-STX - Zwart

ASRock DeskMini 310 - Barebone - Mini-STX - 1 x Socket 1151v2 - DDR4 2400 MHz, 2 x SO-DIMM slots, Max. 32GB - HD Graphics - GigE - Zwart - 120W/19V Power Adapter
Niet op voorraad
SKU
90BXG3701-A10GA0W
€ 149,00 Voorbestelling
Bestel binnen en ontvang tussen 4 tot 6 dagen

Op werkdagen vóór 17.00 uur besteld en op voorraad nog dezelfde dag verzonden. Lees meer...

Gratis verzending boven 100 euro.

Bel ons voor meer informatie over onze producten.

14 dagen bedenktijd.

Wij bestaan al meer dan 20 jaar!

DeskMini 310 Series
  • Supports Intel® 8th Core™ / Pentium® / Celeron® LGA1151 processors
  • Dual DDR4 SO-DIMMs, up to 32GB
  • Triple Video outputs: DisplayPort, HDMI & D-Sub
  • 1 x Ultra M.2 PCIe Gen3 x4 Slot
  • 2 x 2.5" HDD/SSD Tray
  • 1 x M.2 (2230) Wi-Fi Slot
  • USB 3.1 Gen1 Type-C port
  • Micro SD Card Reader

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.

DeskMini 310 Barebone

  • Dimension
    - 155 x 155 x 80 mm
  • CPU
    - Supports Intel® 8th Processors (Socket 1151)(Max. TDP 65W)
  • Chipset
    - Intel® H310
  • Memory
    - Supports DDR4 2666MHz, 2 x SO-DIMM Slots, Max. 32GB
  • Graphics
    - Supports Intel® UHD Graphics
  • Graphics Output
    - 1 x HDMI, 1 x DP, 1 x VGA
  • Audio
    - 1 x Head Phone with MIC Jack, 1 x MIC-In
  • USB
    - Rear: 1 x USB 2.0 Type-A, 1 x USB 3.1 Gen1 Type-A
    - Front: 1 x USB 3.1 Gen1 Type-C ,1 x USB 3.1 Gen1 Type-A
  • LAN
    - Intel® Gigabit I219V LAN
  • Storage
    - 2 x SATA3 with Power connectors
    - 1 x Ultra M.2 (2280) SSD Slot (PCIe Gen3 x4 / SATA6Gb)
    - 1 x Micro SD Card Reader (bottom side)
  • WiFi
    - 1 x M.2 (key E 2230) Slot for Wi-Fi + BT Module
    - Support Intel® CNVi module, PCIe
  • Front I/O
    - 2 x USB 2.0 Headers, 1 x Front Panel Header,
    - 2 x 4-Pin fan connectors (CPU, SYS), COM Port
    - 1 x DC-In Jack (Supports 19V Power Adapters)
    - 1 x Internal Speaker Header (4-Pin)
    - 1 x Chassis Intrusion Header (2-Pin)
  • Rear I/O
    - 1 x HDMI*
    - 1 x DP*
    - 1 x VGA*
    - 1 x USB 2.0 Type-A
    - 1 x USB 3.1 Gen1 Type-A

    *Three graphics output options : HDMI,DP ,VGA and supports up to 2 displays simultaneously.
  • Certification
    - CE, FCC
  • Remark
    - Supports TPM 2.0
Meer informatie
EAN 4717677335651
Multi-Core Technologie N.v.t.
Processor Zonder CPU
RAM 0 MB
Geheugentype DDR4 (SODIMM)
Geheugengrootte Leeg
Harde schijf Geen
Graphics controller Intel HD Graphics
Besturingssysteem Nee
